Sistema

Risposta in freuenza
35Hz - 20kHz ±2dB Frequenza di taglio del crossover
2300Hz 3rd Harmonic Distortion@ 90dB SPL, 1m,
500-7kHz 0.08% 3rd Harmonic Distortion @ 90dB SPL, 1m,
200 - 20kHz 0.2% 3rd Harmonic Distortion @ 90dB SPL, 1m,
1.5% Acoustic Output - SPL @ 1m, Long term
(80Hz - 20kHz) 105dB Acoustic Output - SPL @ 1m, Peak
(80Hz - 20kHz) 108dB Ingresso audio
XLR, RCA (balanced/unbalanced)

Woofer

Diametro 180mm (7.1") Configurazione Voice Coil
High temperature single coil Diametro Voice Coil
38mm (1.5") Material High-strength Polyamide - Glass Fiber Magnet Type Ferrite Cone Type Mineral Filled Polypropylene Magnetic Shielding Bucking magnet and steel cap
Tweeter

Diametro della capsula
25.4mm (1") Diametro Voice Coil
25mm (0.98") Magnet Type Ferrite Dome Type Silk Gap Design Ferrofluid Cooled Magnetic Shielding Bucking Magnet
Amplificatore

Risposta in frequenza
20Hz - 20kHz(±0.2dB) Operating Band Pass 20Hz - 2400Hz (LF)/2400Hz - 20kHz (HF) Total Harmoic Distortion 0.01% 120 Watts into 4 Ohm Load Long Term Power @ 4 Ohms 80 Watts Burst Power @ 4 Ohms 120 Watts Output Topology Class AB LF Trim Constantly variable ±3dB HF Trim Constantly variable ±3dB Subsonic Filter -3dB @ 30Hz Driver Protection Current Limiting Temperature Protection Thermal Cut-Off Switch Indicators Event badge 'On' mode Cooling Convection - Aluminium Heat Sink Power Requirements Voltage selector 110-120V or 220-240V, 50/60Hz, 180VA
Power via detachable 3 circuit IEC type linecord
Physical

Cabinet Construction MDF Low Frequency Vents Front Port Dimensioni Cabinet 260mmW x 375mmH x 300mmD
(10.2"W x 14.8"H x 11.8"D) Peso Cabinet
17kg (37.48lb) Dimensioni imballo
375mmW x 495mmH x 415mmD
(14.8"W x 19.5"H x 16.3"D) Peso del monitor imballato
19kg (41.88lb)
