CARATTERISTICHE TECNICHE:

System type
2-way coaxial vented stage monitor
Low Frequency Device
10” woofer with 2"VC
High Frequency Device
1” compression driver with 1"VC
Angular Coverage
80°
Frequency response
60 Hz - 20 kHz
Max SPL at 1mt (peak)
123 dB
Amplifier Continuous Power
HF: 50 W CLASS AB, LF: 200W CLASS D with SMPS
Input Impedance
30 kohm balanced, 15 kohm unbalanced
Input Sensitivity
0 dBu
Controls
LEVEL, PRESET selector (MONITOR, FOH), GND lift
Connectors
INPUT: COMBO (XLR-F/JACK), LINK: XLR-M
Power Supply
230 VAC or 120 VAC - 50/60 Hz
Maximum Consumption
315 W
Rated Consumption*
165 W
Construction
Plywood with black anti-scratch polyurethane paint
Pole Adapter
1 x side
Handles
2 x sides
Monitor taper
36°
Weight
12 kg (26,4 lb)
Dimensions (W x H x D)
490x265x375 mm
