Caratteristiche principali:

1400 watt 2-way peak power
130 dB max SPL
Digital bi-amplification, SMPS
DSP sound processing
90° x 60°, wide dispersion constant directivity horn
12" woofer, high power, 2.5" voice coil
1.0" HF driver, titanium dome, neodymium 1.5" voice coil
FiRPHASE processing
ACOUSTICAL SPECIFICATIONS
Frequency Response -3 dB:45 Hz ÷ 20 Hz
Max SPL:130 dB
Horizontal coverage angle:90°
Vertical coverage angle:60°
Compression Driver:1", 1.5" voice coil
Woofer:12", 2.5" voice coil
INPUT/OUTPUT SECTION
Input signal:bal/unbal
Input connectors:Jack-XLR male
Output connectors:XLR female
Input sensitivity:-2 dBu / + 4 dBu
PROCESSOR SECTION
Crossover frequencies:1600 Hz
Protections:thermal, RMS
Limiter:soft limiter
Controls:Volume, EQ shape, Mic/line
AMPLIFIER SPECIFICATIONS
Total power:1400 W PEAK
High frequencies:400 W PEAK
Low frequencies:900 W PEAK
Total power:700 W RMS
High frequencies:200 W RMS
Low frequencies:500 W RMS
Cooling:convection
Connections:VDE
CABINET
Cabinet Material:Composite PP
Hardware:1 x M10 top, 1 x M10 bottom, 3 x M6 bottom
Handles:1 top, 2 side
Pole Mount/Cap:Yes
Grille:Steel
Colour:Black
PHYSICAL SPECIFICATIONS
Height:647/25.47 mm/inch
Width:380/14.96 mm/inch
Depth:380/14.96 mm/inch
Net Weight:17.4/38.36 kg/lbs
