Caratteristiche tecniche
Keyboard 88 keys (Ivory Feel-G keyboard)
Touch Sensitivity Key Touch: 3 levels, Fixed Touch
Keyboard Modes Whole Dual (volume balance adjustable) Split (split point, volume balance adjustable) Twin Piano
Sound Generator
Piano Sound SuperNATURAL Piano Sound
MIDI Format Conforms to GM2, GS
Max. Polyphony 128 voices
Tones Piano: 6 Tones E.Piano: 7 Tones Other: 22 Tones
Stretched Tuning (only for piano tones) Always On
Master Tuning 415.3 Hz to 466.2 Hz (adjustable in increments of 0.1 Hz)
Transpose -6 to +5 (in semitones)
Effects Ambience (Off, 1 to 4) Brilliance (Mellow, Normal, Bright) Only for Piano Tones: String Resonance (Always On) Damper Resonance (Always On) Key Off Resonance (Always On)
Recorder
Part 1 part
Save Format Standard MIDI Files (Format 0)
Note Storage Approx. 30,000 notes
Controls Song Select Play/Stop Rec Tempo Count-in Mix Balance All Song Play
Tempo Quarter note = 20 to 250
Resolution 120 ticks per quarter note
Metronome
Tempo Quarter note = 20 to 250
Beat 0/4, 2/4, 3/4, 4/4, 5/4, 6/4
Audio
Playback File Format: Audio File (WAV 44.1 kHz, 16-bit linear format)
Controls Song Select Play/Stop Playback Speed
Internal Memory
Save Song Standard MIDI Files (Format 0)
Songs Max. 1 song
External Memory
External Storage USB Flash Memory
Songs Max. 99 songs
Rhythm
Rhythms 32 types
Controls Rhythm Select Start/Stop Tempo Mix Balance
Tempo Quarter note = 10 to 250
Playable Song Format Standard MIDI Files (Format 0, 1) Roland original format (i-Format) Audio File (WAV, 44.1 kHz, 16-bit linear format)
Save Format Standard MIDI Files (Format 0)
Other
Internal Songs 30 songs
Rated Power Output 6 W x 2
Speakers 8 x 12 cm (3-3/16 x 4-3/4 inches) x 2
Volume Level (SPL) 96 dB (This value was measured according to the method that is based on Roland's technical standard.)
Language English
Control Volume
Pedals Damper (capable of continuous detection)
Other Functions Panel Lock V-LINK MIDI Visual Control Tone Demo Auto Off Roland Wireless Connect (wireless LAN function *2) *2: Wireless USB Adapter sold by Roland is required.
Connectors DC in jack Pedal connector Output jack: Stereo miniature phone type (usable as Phones jack) Phones jack: Stereo miniature phone type USB MEMORY port: USB Type A USB COMPUTER Port: USB Type B
Power Supply AC adaptor
Power Consumption 9 W (2 W to 18 W) 9 W: Average power consumption while piano is played with volume at center position 2 W: Power consumption immediately after power-up; nothing being played 18 W: Rated power consumption
Accessories Owner's Manual Music Rest AC Adaptor Power Cord (for connecting AC Adaptor) Damper pedal (capable of continuous detection)
Options (sold separately) Dedicated Stand: KSC-68 Keyboard Stand: KS-18Z, KS-12 Damper Pedal: DP-10 USB Flash Memory *3 Wireless USB Adapter: WNA1100-RL *3 *3: Use USB flash memory and Wireless USB Adapter sold by Roland. We cannot guarantee operation if other products are used.
Size and Weight (With music rest detached:)
Width (W) 1,282 mm50-1/2 inches
Depth (D) 296 mm11-11/16 inches
Height (H) 132 mm5-1/4 inches
Weight 20 kg44 lbs. 2 oz.
Size and Weight (With music rest and dedicated stand KSC-68:)
Width (W) 1,282 mm50-1/2 inches
Depth (D) 415 mm16-3/8 inches
Height (H) 916 mm36-1/16 inches
Weight 28 kg61 lbs. 12 oz.
