Caratteristiche principali:

Mixer con effetti
Connettori di ingresso : Mic Input Balanced XLR-F - Combo - Line Input Balanced TRS Jack - USB
Ingressi : 12 MIC - 8 Line - 4 stereo line - USB
Sensibilità ingresso : Mic Input from 0 to -60 dB - Line Input from +20 to -40 dB
Impedenza di ingresso : Mic Input 2 Kohm - Line Input 10 Kohm
Connettori di uscita : Balanced TRS Jack and / or XLR-M - USB
Uscite : CROOM - MAIN MIX - GROUP 1-2 - AUX 1, 2 & 3 - PHONES - USB
Livelli di uscita : MAIN MIX nom. out level +4 dBu - all other outputs 0 dBu - Maximum level all outputs +22 dBu
Impedenza uscita cuffia : min. impedance 32 ohm - max. out level (2x) 193 mW
Distorsione (THD+N) : at +4dB, 1kHz < 0,008 %
Equalizzazione canale ingresso mono : Lo Cut 75 Hz, 18 dB/oct. HIGH (shelving) ±15 dB @ 12KHz MID (peaking) ±15 dB from 100 Hz to 8 kHz LOW (shelving) ±15 dB @ 80Hz
Equalizzazione canale ingresso stereo : HIGH (shelving) ±15 dB @ 12KHz HI-MID (peaking) ±15 dB @ 3 KHz LO-MID (peaking) ±15 dB @ 500 Hz LOW (shelving) ±15 dB @ 80Hz
Effetti incorporati : HALL, ROOM, VOCAL and PLATE reverbs, MONO, STEREO and TAP DELAY, CHORUS and FLANGER, REV + DELAY, REV + CHORUS and REV + FLANGER
16 step PRESET selector
16 step VARIATION selector
PEAK LED
MUTE and TAP DELAY switch with LED indicator and footswitch
Rumore : unweighted < -93 dBu
Peso Netto : 6.5 kg(14.332lb )
Dimensioni (L x A x P) : 48.5 x 9 x 43.5 cm
