PRESONUS STUDIO 1810C
SCHEDA AUDIO
PRESONUS STUDIO 1810C
SCHEDA AUDIO
PRESONUS STUDIO 1810C
SCHEDA AUDIO
CARATTERISTICHE TECNICHE:
INPUT/OUTPUT
Simultaneous I/O up to 18 inputs/8 outputs (8x6 at 192 kHz)
2 mic/instrument/line inputs with XMAX Class A mic preamps
2 mic/line inputs with XMAX Class A mic preamps
4 balanced ¼” TRS direct-to-ADC line inputs
8 channels of ADAT Optical input (4 channels at 96 kHz)
>DC coupled for sending control voltages
4 balanced ¼” TRS line outputs for monitor mixing
>DC coupled for sending control voltages
2 stereo headphone outputs with the same mix or independent mixes
MIDI In/Out
Stereo S/PDIF digital I/O
1 USB-C 2.0 port
INTEGRATED SOFTWARE
Studio One® Artist for Mac® and Windows®
UC Surface control software for Mac, Windows, iPad®, and Android™
Studio Magic Plug-in Suite
METERS, CONTROLS, AND FEATURES
18x6 onboard DSP monitor mixer
Front-panel mute and level controls for main outputs
True +48V phantom power for condenser microphones (global)
6 ladder-style 8-LED level meters (4 input, 2 main output)
DIGITAL
USB-C port (USB 2.0)
24-bit resolution
44.1, 48, 88.2, 96, 176.4 and 192 kHz sampling rates
PHYSICAL
Road-rugged construction with all-metal chassis and metal knobs
SPECIFICHE TECNICHE:
GENERAL
Sample Rates 44.1, 48, 88.2, 96, 176.4, 192 kHz
Converter Resolution 24-bit
Converter Dynamic Range 114 dB
Converter Dynamic Range 114 dB
MICROPHONE INPUTS
Maximum Level +16 dBu, min gain
Gain Range 80 dB
Frequency Response 20 Hz - 20 kHz (unity gain)
Dynamic Range 110 dB (A-wtd, min gain)
THD + N 0.005% (1 kHz, 0dBu, unity gain)
EIN -128 dBu (A-wtd, 20 kHz BW, Rs=150?, max gain)
Input Impedance 1400?
Phantom Power 48V (>10 mA per channel)
LINE INPUTS
Maximum Level +21 dBu (balanced, min gain)
Gain Range 40 dB
Frequency Response 20 Hz-20 kHz (unity gain)
Dynamic Range 112 dB (A-wtd, min gain)
THD + N 0.005% (1 kHz, +18 dBu, min gain)
Input Impedance 10 k?
INSTRUMENT INPUTS
Maximum Level +15 dBu (unbalanced, min gain)
Gain Range 80 dB
Frequency Response 20 Hz - 20 kHz (min gain)
Dynamic Range 112 dB (A-wtd, min gain)
THD + N 0.020% (1 kHz, +10 dBu, min gain)
Input Impedance 1M ?
MAIN OUTPUTS
Type ¼" TRS female, DC Coupled
Maximum Level +18 dBu, balanced
Frequency Response 20Hz - 20kHz (unity gain)
Dynamic Range 108 dB (A-wtd, unity gain)
THD + N 0.004% (1 kHz, -1 dBFS, unity gain)
LINE OUTPUTS
Type ¼" TRS female, DC coupled
Maximum Level +18 dBu, balanced
Frequency Response 20 Hz - 20 kHz
Dynamic Range 108 dB (A-wtd, -60 dBFS)
THD + N 0.004% (1 kHz, -1 dBFS, unity gain)
HEADPHONE OUTPUTS
Maximum Power 150 mW/channel (60? load)
Frequency Response 20 Hz - 20 kHz (unity gain)
Dynamic Range 103 dB (A-weighted, 1 kHz, unity gain)
THD + N 0.250% (1 kHz, 150 mW, unity gain)
Impedance Working Range 32? to 600?
PHYSICAL
Height 1.75" (44 mm)
Width 12.5" (317 mm)
Depth 5.5" (140 mm)
Weight
3.2 lbs (1.45 kg)
REQUISITI DI SISTEMA:
MAC
Mac® OS X 10.8.5 64-bit or later
Intel® i-series 2 GHz multicore processor (or AMD equivalent) or faster
4 GB RAM (8 GB or more recommended)
WINDOWS
Windows® 7 x64/x86 SP1 + platform update, Windows 8.1 x64/x86, Windows 10 x64/x86
Intel i-series 2 GHz multicore processor (or AMD equivalent) or faster
4 GB RAM (8 GB or more recommended)
MAC AND WINDOWS SYSTEMS
USB-C or USB-A 2.0 port
32 GB hard disk space
PreSonus Universal Control 2.0 or higher
Monitor with 1366x768 resolution (high-dpi monitor recommended)
Multitouch-enabled monitor required for touch operation
IOS
iOS 9.3 or later
iPad Pro, iPad Air 2, iPad Air, iPad mini 4, iPad mini with Retina display, iPad (4th generation), iPad mini, iPad (3rd generation), iPad 2?
ANDROID
Android™ 5.0 (Lollipop) or later
Android tablet (8-inch) with 1024x768 resolution (UC Surface)
